10MP USB 2.0 High-Sensitivity CMOS C-Mount Camera – Bundled with Reduction Lens for Flexible Imaging

Description

The MU1000B is an updated version of our MU series cameras. With the universal USB 2.0 interface, this bus-powered 10MP camera is a go-anywhere imaging solution. Deriving power from the USB connection, MU series cameras can be used at home, in a lab, or in the field. The industry-standard C-mount design allows this camera to be connected directly to C-mount photo-ports, or used in conjunction with an array of lenses and adapters to mount to virtually any popular microscope line.

With software available for Windows, Mac, and Linux, the MU series is a multi-platform imaging solution. The included Windows software offers image-development and measurement tools, as well as advanced compositing features such as image-stitching and extended-depth-of-focus. With the ability to calibrate scales at multiple magnifications, the software can be used for multi-level inspection. Independent preview and capture resolutions allow you to view high-speed video while simultaneously capturing high-definition images. For Mac and Linux, there is a lite version of the software which can capture video and still images, and includes limited processing features.

Camera Specifications:

Sensor: Aptina MT9J003 (color)

Sensor Type: CMOS

Sensor Size: 6.44×4.62mm (1/2.3″ class)

Pixel Size: 1.67 micrometers

Resolution: 10MP

Frame Rate: 35fps @ 896×684, 13fps @ 1792×1372, 3.7fps @ 3584×2746

Sensitivity: .31V/Lux-sec

Connectivity: USB 2.0

Compatibility: Windows (32/64 bit) XP/Vista/7/8/10, Mac OSX, Linux

Mounting Sizes: 23mm, 30mm, 30.5mm, and C-mount

Software Specifications:

OS Requirements: Windows (32/64 bit) XP/Vista/7/8/10, Mac OS 10.8+, Linux kernel 3.13+

Hardware Requirements: Intel Core2 2.8GHz or comparable processor, 2GB RAM, USB2.0

Advanced software for Windows:
– offers Stitching, EDF, video recording and measurement functions
– conducts measurements for lengths, angles, arcs, areas and etc.
– saves still images in BMP, TIFF, JPG, PICT, PTL or other formats
– live video and still image capture can be set in different resolutions simultaneously
More features: add layers, watermarks, mosaics, tiles; adjust color balance, exposure, saturation, contrast, orientation; change resolution, histogram, granulation, diffusion; transform images via edge detection, digital image warping; conducts measurements for single, parallel or perpendicular lines and rectangular, elliptical and irregular areas; adds notes, measurements, text, arrows, labels, and etc. using customizable text with different sizes and colors; conducts measurements in microns, millimeters, centimeters, inches, feet, and etc. under any magnification powers with desired tolerances

Lifetime free software upgrades

Contents:

One 10MP USB2.0 Digital Camera

One Reduction Lens

One 6′ (1.8m) USB Cable

Two Adapters: 30mm and 30.5mm

One CD with Software and User’s Instructions
